C+E Announces the Award of Patent for its Transformative Technology Targeting a New Paradigm for Sustainable Water Supply.
Susanne Chess, Communications Director
SANTA BARBARA, CA (March 18, 2022) —
Chess+Evans LLC announces the award of Israel Patent Number 272545 for a Submersible Desalination System. Patents cover equipment, processes, and methods that address the cost and complexities of producing fresh water from deep ocean water (DOW). Operation within this environment avoids the intake of plankton and other biomass, reducing the concentration of brine to eliminate its accumulation and lower energy cost. The technology addresses the lifecycle requirements deployment, installation, and recovery, or removal, from depth, subsea operation, collection, storage, extraction, and purified water delivery to surface or shore. Patents include using ~3% differential in relative density between produced fresh water and ambient saline water as a safe and stable means of buoyancy control—an innovation with applications across multiple offshore sectors, such as lifting equipment or lowering the cost and risk of platform decommissioning.
The Tiabzu Desalination System is contained within a submersible vessel to immerse in a body of water at depths where naturally occurring hydrostatic pressure forces seawater through reverse osmosis filters to lower energy costs by 40% compared to coastal desalination. Operation below the ocean’s photic zone where 90% of marine life exists eliminates much of the detrimental environmental impact of coastal or seawater desalination drawn from surface waters. Methods facilitate operation above the seafloor, addressing impact to benthic (mud bottom) community and challenges of silting.
The submersible fits in a standard container for ground, air, and ship transport and launches using ramps, lower-cost shore-based cranes, and smaller-tow vessels. Compatibility with this commonly accessible harbor infrastructure facilitates mobility for quick response for emergency or humanitarian needs and intermittent or peak supply for coastal or island communities. Claims include methods of mineralization to deliver potable or water of specified chemistry for medical, commercial, or industrial purposes.
Modules can also be deployed in clusters or arrays and connected to offshore or inshore infrastructure for power with pipelines to transport purified water to shore for industrial-scale production. Each module scales to produce between 250 – 1000 gallons per minute each; More than one million gallons per day of purified water from seawater.
According to Tim Foresman, Ph.D., Former Chief Scientist for the United Nations Environment Programme, who participated in reverse osmosis systems development with the U.S. Naval Civil Engineering Laboratory (NCEL),
“The brilliance of C+E’s work is to effectively integrate an engineered solution that advances the state-of-the-art for comprehensive management of coastal resources while generating renewable potable water sources. Their technology offers a solution not only for energy savings but targets the core need for a new sustainable paradigm within the seawater desalination industry. This is a solution with special emphasis on its impact on ocean life and ocean systems, and their relationship to climate change.”
Co-developer Bob Evans states, “This is our fourth patent awarded, but Israel is special. It is, of course, respected as the technological leader for water supply by desalination. My grandfather, Victor Caliva manufactured in his Los Angeles-based Aircraft Foundry and filled liberty ships full of cast aluminum pipe fittings to the State of Israel for their original irrigation system. It is an honor to add Susanne and my technology to our family legacy.”
About Chess+Evans LLC
Bob Evans and Susanne Chess co-founded Chess + Evans LLC in 2017 to umbrella a team of visionaries and engineers to develop the technology and tools necessary to:
- Secure a resilient, economically, and environmentally superior source for freshwater from seawater+
- Contribute toward a sustainable future with water supply solutions that do not disrupt the marine population that supplies most of the air we breathe and sequesters CO2 in the deep ocean as part of a natural planetary climate regulating process.
- Contribute toward the creation of a new and sustainable offshore economy.
Chess+Evans LLC has made significant strides in research, development, concept design through the feasibility of transformative technology. They have formed a strategic industrial alliance that catalyzes more than 100 years of combined experience in developing internationally acclaimed ocean-related products, managing offshore projects, and reverse osmosis and process engineering to achieve these goals.
In 2023, C+E became Tiabzu LLC to reflect its participant growth and to prepare for global commercialization.
IMAGES: Permission for use of images extends only to those publishing the corresponding press release. For all other uses, please contact the media representative for C+E. © Chess+Evans LLC. All Rights Reserved.
